GROOVELINE

rack.1

rack 1

GROOVELINE

Component	Dimension	Details
Overall Width	1200 mm	Total span from edge to edge
Height	1200 mm	Front elevation vertical height
Depth (Side Projection)	400 mm	Depth from wall to face
Groove Spacing	141 mm c/c	Repeating groove detail
Groove Width	8 mm	Cut depth into ply
Groove Depth	8 mm	As per detail A
Ply Thickness	18 mm	Core panel material
Side Return Panel	300 mm	Return end depth dimension

Category: Racks Tags: display, racks, shelves

Description

A symmetrical wall-mounted feature rack with horizontal slatted grooves, designed for visual rhythm and material expression. Combines minimalist ply layering with decorative grooves for a refined architectural element.

Additional information

Specifications	Primary Material: 18 mm thick plywood, finished in selected veneer or laminate Consistent across faces, sides, and detailing Finish Options: Matte PU finish or Laminate/Veneer, per client or designer selection Slatted panels treated uniformly Grooves: CNC-cut 8 mm x 8 mm grooves, repeated at 141 mm center spacing Adds texture and linearity to the otherwise flat ply surface
Instructions	Joinery: Screwed back panels (not visible from front) Grooves spaced using precision CNC or jig template Side elevation shows layered ply buildup and groove carving Installation: Wall-mounted, preferably on concealed metal brackets or directly fastened to wall backing Screws suggested at rear, hidden from front elevation
