VERTOWOOD

Component Dimension Details
Overall Width 2400 mm Width of the entire rack
Overall Height 3000 mm Full height from floor to top
Depth of Unit 450 mm (max) From front face to back wall
Shelves 900 mm wide (curved ends) Laminated shelves, 25 mm thick
Shelf Thickness 25 mm Horizontal support, laminated
Shelf Spacing ~390 mm vertically From bottom to top across 5 levels
Vertical Panels 450 mm deep PU-finished MDF/HDHMR, defines the modular sections
Decorative Discs (Dia.) Ø150 mm, Ø100 mm, Ø50 mm Highlight elements at intersections
Radius of Curves R65 (main curved face edges) Smooth concave and convex transitions
Category: Tags: , ,

Description

A feature wall unit designed as a striking visual and functional centerpiece, combining curved laminated shelves and matte-finished vertical panels. The unit integrates stylized circular decorative panels and is ideal for high-end living spaces, lobbies, or retail showpieces.

Additional information

Specifications

Shelves:
Material: HDHMR / Ply Core
Finish: Laminate (PU-matched or in contrast, as per selection)
Shape: Custom CNC cut curved profiles (as per plan)
Vertical Panels:
Material: MDF / HDHMR
Finish: PU Paint (Matt black or other designer finish)
Thickness: Approx. 25–30 mm for solid paneling
Decorative Circular Discs:
Material: Wood / MDF
Finish: PU paint in specified tones
Sizes: Ø150, Ø100, Ø50 mm as per layout
Back Panel (if applicable):
Material: Plywood or MDF
Finish: PU paint or laminate (optional depending on open/closed design)
Instructions

Installation:
Fix vertical members securely into floor or support base
Mount shelves into routed slots or supported with concealed brackets
Align decorative discs with center points of intersection
Application:
Suited for lobby features, residential living walls, boutique store walls
Can hold books, decor items, vases (light to medium load recommended)
Care & Maintenance:
Clean PU surfaces with microfiber cloth
Avoid abrasive cleaners on laminated and PU-coated areas
Check alignment of discs and shelves periodically
